Industrial Nova Series Diaphragm Valves Fluid Control Low Internal Volume

Name: Industrial Nova Series Diaphragm Valves Fluid Control Low Internal Volume
Brand: PAEKER
Price: 158 USD

Brand Name : PAEKER

Model Number : Nova Series Diaphragm Valves

Place of Origin : china

MOQ : 2

Price : $158

Payment Terms : T/T

Supply Ability : >10

End Connections : Threaded

Flow Rate : 50 GPM

Mounting Style : Inline

Application : Industrial

Seal Material : PTFE

Temperature Rating : Up to 400°F

Type : Control Valve

Pressure Rating : 1500 psi

Material : Stainless Steel

Port Type : Full Port

Actuation : Manual

Body Style : 2-Way

Size : 1 inch

Contact Now

Product Description:

### NOVA Series Valves: Economical and Versatile for Diverse Applications Discover the NOVA Series valves, the go - to choice for cost - effective fluid control. Ideal for regulator outlet valves, gas control panels, and analyzer sampling systems, these general - purpose diaphragm valves offer great value. Built with a 316L stainless - steel body, they ensure durability. The variety of seat materials and an Elgiloy® diaphragm with a metal - to - metal external seal guarantee leak integrity, enhancing safety and reliability. For more automated needs, the NOVA AOP Series Air Actuated Diaphragm Valve is a top pick. Derived from the manually operated version, it comes in normally open or normally closed configurations. With two line pressure options (250 psig and 500 psig), it provides flexibility for different setups. Whether you're in the chemical, energy, or analytical industry, NOVA Series valves are designed to meet your fluid - handling requirements efficiently.

Product Features:

• High Cycle Life
• Compact Size
• Positive, consistent shutoff
• Metal to Metal seal to atmosphere
• Low Internal volume
• Low actuation pressure for AOP configuration

Specifications:

Parameter	Details
Functional Performance - Pressure Ratings
Manual Valve - Operating Pressure	Vacuum to 3500 psig (241 bar)
Manual Valve - Proof Pressure	5,250 psi (362 bar)
Manual Valve - Burst Pressure	10,500 psi (724 bar)
AOP1, AOP3 Valve - Operating Pressure	Vacuum to 250 psig (17 bar)
AOP1, AOP3 Valve - Proof Pressure	375 psi (26 bar)
AOP1, AOP3 Valve - Burst Pressure	750 psi (52 bar)
AOP2, AOPNO Valve - Operating Pressure	Vacuum to 500 psig (34 bar)
AOP2, AOPNO Valve - Proof Pressure	750 psi (52 bar)
AOP2, AOPNO Valve - Burst Pressure	1,500 psi (103 bar)
Seat Leakage Class	Bubble Tight
Temperature Rating	-15°F to 150°F (-26°C to 66°C)
Flow Capacity	Cv = 0.17
Orifice Diameter	.125 inch (3.2 mm)
Internal Volume	Less than 1.0 cc
Approximate Weight	0.26 kg
Maximum Actuation Air Pressure - AOP1 (normally closed)	65 psig (4.5 bar)
Maximum Actuation Air Pressure - AOP2 (normally closed)	75 psig (5.2 bar)
Maximum Actuation Air Pressure - AOP3 (normally closed)	40 psig (2.8 bar)
Maximum Actuation Air Pressure - AOPNO (normally open)	50 psig (3.5 bar)

Product Details:

Industrial Nova Series Diaphragm Valves Fluid Control Low Internal Volume
